PRODUCT STANDART
TS EN 50525-2-31 / BS 6004:2000 TABLE 4b / IEC 60227 PART 3 / VDE 281-3

ELECTRICAL PROPERTIES
Rated voltage
450/750 V

Test Voltage
2500 V

PHYSICAL PROPERTIES

Operating Temperature
70 °C

Short circuit temperature
160 °C

Minimum bending radius
D<8 mm for 4D
8-12 mm for 5D
D>12 mm for 6D

CONDUCTIVE PROPERTIES

Conductor Type
Pure copper

Conductor Class
5

INSULATION MATERIALS

Insulation
PVC / TI 1

CORE COLORS

Yellow-Green - Blue - Brown - Black or other colors

BUILDING MATERIALS

Conductive
Circular compressed flexible stranded Class 5 pure copper conductor accordant with EN 60228.

Insulation
PVC / TI 1
