Structure:
Conductor: Stranded bare copper or tinned copper in accordance with IEC 60228VDE 0295
Insulation: PVC/TI3 in accordance with DIN VDE 0281
Color ID: in accordance with HD 402 Standard
Application Standard: HD 21.3 S3, VDE-0281 Part-3, CE Low Voltage Diretive, 73/23/EEC and 93/68/EEC

Technical data:
Rated Voltage: 300/500V
Test Voltage: 2000V in accordance with DIN VDE 0281 Part 2 HD21.2
Min. bending Radius
Fixed Installation: 12.5×D (Cable OD)
Movable Installation: 12.5×D (Cable OD)
Temperature Range
Fixed Installation: -40℃ To +70℃
Movable Installation: -15℃ To +70℃
